Ducati MULTISTRADA V45 - Main Components and Devices; Position on the Vehicle

Main components and
devices
Position on the vehicle
1) Windscreen
2) Exhaust silencer
3) Seat lock
4) Central stand
5)   and USB 
 charging only)
6) Tank filler plug
7) Rear-view mirrors
8) Front fork preload adjuster
9) Front power socket
10) Side stand
11) Tool kit  and rear power socket
6
7
8
9
1
7
53
2
4
1011
Fig 9
37
