Tank filler plug
Opening
flap (1) and the active or passive key in the
lock. Turn the key clockwise by 1/4 of a turn to release
the lock.
the plug (2).
Closing
Close the plug (2) with the key and push it
down into its seat. Remove the key and close flap (1)
protecting the lock.
Note
Plug can only be closed when key is
refuelling, always make sure that the plug
is in place and closed.
Electric filler plug opening (option)
The electronic plug can be opened within 50
seconds from the
Fig 10
Fig 11
38
