Charging the
Charging the
Before charging the it is best to remove it
from the motorcycle.
Undo the screw (2) and remove (1) mounting
bracket (3).
the protective sheath (4) and then unscrew the
retaining screws (5) and remove the following from
the corresponding terminals:
- the negative cable (6);
- the positive cable (7).
Remove the (1) sliding it upwards.
The gives explosive gases; never
cause sparks or allow naked flames and
near the When charging the ensure
that the working area is properly ventilated.
Charge the in a ventilated room.
Connect the charger leads to the
terminals: the red one to the positive terminal (+),
the black one to the negative terminal (-).
Charge the at 0.9 A for 5÷10 hours.
Keep the out of the reach of children.
Fig 283
Fig 284
281
