Ducati MULTISTRADA V45 - Page 41

Turn the bayonet  (6) anticlockwise to release
them, carefully  the rider seat (8) and disconnect
the rider seat heating connector (7).
Slide the rider seat (8) towards the rear end, ensuring
that the housings (9) remain in position.
8
6
7
Fig 14
9
8
9
7
Fig 15
40
