 the seats and height configuration
Note
Rider seat and passenger seat must have the
same configuration.
On this vehicle, the seat height is adjustable.
When the rider seat (8) is removed, it can be adjusted
by  the seat  (C) into the following
housings:
- upper one (position A, high seat);
- lower one (position B, low seat).
Lower the rider seat (8) at the rear, connect the
connector (7) and check the correct positioning of
the seat on the housings (9).
8
C
A
B
Fig 16
9
8
9
7
Fig 17
41
