Position the passenger seat (1) by  the pin
(10) at the housing (D).
Connect the connector (5) and lay cable (3) in cable
ring (4).
Take care to  the tabs (11) on both sides of the
seat, at the rear, into the following housings:
- A, rear for high seat;
- B, front for low seat.
Press down at the pin (10) to lock the passenger seat.
Note
Both seats are heated; see the sub-section
"Heated seat" on how to operate them.
3
5
4
D
2
4
Fig 20
11
B
A
Fig 21
43
