Connect the negative cable (4) and the ABS negative
cable (5) to the negative terminal of the
always from the positive (+), and the
screws (1).
Refit the cover (A), reposition the elastic
band (C) and tighten screw (D).
Refit the seat as described in chapter “Seat lock”.
The gives explosive gases; never
cause sparks or allow naked flames and
near the When charging the ensure
that the working area is properly ventilated.
Connect the charger leads to the
terminals: the red one to the positive terminal (+),
the black one to the negative terminal (-).
Ducati disclaims any liability deriving from the use of
non-original Ducati chargers or maintainers.
It is recommended to use the Ducati dedicated
charge maintainer Maintenance Kit
no. 69928471A (Europe), no. 69928471AW
(Japan), 69928471AX (Australia), 69928471AY (UK),
69928471AZ (USA), available from our sales
network), and to operate as described in the sub-
section “Maintaining the charge”.
Keep the out of the reach of children.
Before activating the charger, connect
it to the always with the red positive
terminal (+) first.
NEVER connect the in parallel with
that of other vehicles, as this may cause a
circuit or overheating of the
174
