Parameter displaying
Upon key-on, the instrument panel carries out a
check routine to test the warning lights and the
display:
warning lights will be turned on in a sequence, while
on display system shows the version and
progressively activates rpm bar indicator and speed
indication.
At the end of the check, the instrument panel
displays the main screen (standard screen) showing
the available functions and turns on the warning
lights, if necessary.
During this first check stage, if the motorcycle speed
exceeds 5 km/h (3 mph) (actual speed), the
instrument panel will immediately stop warning light
and display check routine and display the main
screen.
Fig 56
