Instrument panel
(Dashboard)
Instrument panel
1) LIQUID CRYSTAL DISPLAY (LCD).
2) REV COUNTER.
It indicates engine rpm value.
3) NEUTRAL LIGHT N (GREEN).
Comes on when in neutral position.
4) HIGH BEAM LIGHT
(BLUE).
It turns on to indicate that the high beam lights are
on and when the flasher is activated.
5) ENGINE OIL PRESSURE LIGHT
(RED).
Comes on when engine oil pressure is too low. It
must turn on at "KEY-ON", but must turn  a few
seconds  the engine has  It may 
come on when the engine is hot, however, it should
go out as the engine revs up.

If the ENGINE OIL light stays ON, stop the
engine or it may  severe damage.
6) FUEL WARNING LIGHT (AMBER YELLOW).
Comes on when fuel is low (see chapter Top-ups).
7) TURN INDICATOR LIGHTS
(GREEN).
A warning light turns on and blinks when the
relevant turn indicator is active; when the warning
lights blink at the same time, the HAZARD function
is active.
8) "ENGINE/VEHICLE DIAGNOSIS - MIL" LIGHT
(AMBER YELLOW).
The warning light turns steady on in case of error
in engine management. Proceed slowly, avoid
harsh acceleration and  take the
vehicle to a Ducati authorised service centre to
eliminate the malfunction.
The warning light turns on flashing to warn
about a critical emission-related error that could
damage the catalytic  If possible, have
the vehicle be taken to a Ducati authorised
service centre and the malfunction eliminated
and at any rate proceed slowly, avoid harsh
acceleration and 
