Ducati Scrambler User Manual

Maintaining the  charge
Removing the 

Have the  removed at a Ducati Dealer or
authorised Service Centre.
To reach the  it is necessary to remove the
seat .(“Seat lock”) and the  cover (A).
Remove the elastic band (C) and loosen the screws
(D).
Loosen the screws (1), remove the positive cable (2)
and the (ABS) positive cable (3) from the positive
terminal.
Remove the negative cable (4) and the ABS negative
cable (5) from the negative terminal and remove the
 by sliding it out of its housing.
 the 

When  must be  ALWAYS
contact a Ducati Dealer or authorised Service Centre.
Grease the screws (1).
Refit the  and connect the positive cable (2)
and the ABS positive cable (3) to the positive
terminal.
C
A
D
Fig 173
4
5
1
1
2
3
Fig 174
173

Ducati Scrambler Specifications

General

Power	73 hp (54 kW) @ 8, 250 rpm
Transmission	6-speed
Frame	Tubular steel trellis frame
Torque	49 lb-ft (67 Nm) @ 5, 750 rpm
Front Suspension	USD Kayaba 41 mm fork
Rear Suspension	Kayaba rear shock, preload adjustable
Rear Brake	245 mm disc, single-piston caliper
Fuel Tank Capacity	13.5 l (3.6 US gal)
Front Brake	330mm disc, radial 4-piston caliper, ABS
