Ducati Scrambler User Manual

Engine
Twin cylinder, longitudinal 90° "L" type
Bore, mm: 88 mm (3.46 in)
Stroke, mm: 66 mm (2.6 in)
Total displacement, cu. cm: 803 cu. cm (49 cu in)
Compression ratio: 11±0.5:1
Maximum power at  (EU) Regulation no.
134/2014, Annex X, kW/HP:
54 kW/73 HP at 8250 rpm
Maximum torque at  (EU) Regulation no.
134/2014 Annex X:
67 Nm - 6.8 kgm at 5750 rpm
65 Nm - 6.6 kgm at 5750 rpm in China version only
Maximum rpm: 9200

Do not exceed the specified rpm limits in any
running conditions.
Note
The indicated power/torque values have been
measured with a static test bench according to type-
approval standards and match with the data
detected during type-approval process; they are
indicated in the vehicle registration document.
215

Ducati Scrambler Specifications

General

Power	73 hp (54 kW) @ 8, 250 rpm
Transmission	6-speed
Frame	Tubular steel trellis frame
Torque	49 lb-ft (67 Nm) @ 5, 750 rpm
Front Suspension	USD Kayaba 41 mm fork
Rear Suspension	Kayaba rear shock, preload adjustable
Rear Brake	245 mm disc, single-piston caliper
Fuel Tank Capacity	13.5 l (3.6 US gal)
Front Brake	330mm disc, radial 4-piston caliper, ABS
