Electric system
Basic electric items are:
Hermetic type
12V-10 Ah
Generator:
14V - 490W.
motor:
12V-0,7 kW.
Electronic regulator:
protected by a 30A fuse located next to fuse box
(C,Fig 212).
Headlight:
low/high beam: H4 bulb (12V 60/55W);
parking light / DRL: 4 LEDs.
Turn indicators:
front: 3 LEDs.
rear: 3 LEDs.
Electrical controls on handlebars.
Tail light:
parking light: 12 LEDs.
stop light: 18 LEDs.
Number plate light: 3 LEDs.
Instrument panel:
LCD Dashboard.
Note
For bulb replacement instructions, please see
the paragraph "Replacing the high and low beam
bulbs".
Fuses
There are seven fuses that protect the electric
components, located inside the fuse box, and one on
the solenoid The fuse box includes two spare
fuses.
Refer to the table below to identify the circuits
protected by the various fuses and their ratings.
The fuse box (A, Fig 210) is located under the seat so
it is necessary to remove the seat and the
cover to reach it. To expose the fuses, the box
protective cover. Mounting position and ampere
capacity are marked on box cover.
222
