Chapter3AdvancedOperation
Copyright © 2019 Duplo Corporation All Rights Reserved
Adjustable range and correction restrictions
Example: for single fold
Center
Paper
Conveyance
direction
-5.0 mm/0.20 inch
or less
+5.0 mm/0.20 inch
or less
Adjustment by
using the [-] key.
Adjustment by
using the [+] key.
• AdjustablerangeoffoldingpositionA
adjustmentkey/foldingpositionBadjustment
keyonthe[FoldPosition]screenduring
standardfoldingiswithin±5.0mm/0.20inch.
• Thepositionsofthefoldingstoppersof
foldingplates1and2maynotbeadjustable
to±5.0mm/0.20inchaccordingtothelength
of the paper used.
• Forcustomfoldingand[Stopperxingmode],
the folding positions are set directly according
tothepaperlength,andtheadjustablerange
of±5.0mm/0.20inchisnotrestricted.
Therestrictedfoldingplateandadjustmentdetailsdieraccordingtothefoldingmodeandpaperlength.
Folding mode Restricted range of paper length (*) Restricted folding plate Restricted adjustment key
Double fold 182.0to203.9mm/7.17to8.03inches Folding plate 2
key
Irregular accordion
fold-out
182.0to186.7mm/7.17to7.35inches Folding plate 1
key
182.0to199.9mm/7.17to7.87inches Folding plate 2
Letter fold 141.0to150.5mm/5.55to5.93inches Folding plate 2
key
Accordion-fold 141.0to151.1mm/5.55to5.95inches Folding plate 2
key
Gate fold 425.1to432mm/16.74to17.01inches Folding plate 1
key
422.8to432mm/16.65to17.01inches Folding plate 2
key
(*) Rangeofpaperlengthwhichcannotbecorrectedto±5.0mm/0.20inch.Theadjustmentvaluediers
according to the paper length.
Adjustment folding misalignment along vertical length of paper by folding mode
Formisalignmentalongtheverticallengthofstandardfolding,usethefoldingpositionAadjustmentkey/
foldingpositionBadjustmentkeyonthe[FoldPosition]screentoadjust.
“Adjustment method” (p.45)
Folding plate 1 Folding plate 2
Folding mode State of
folded
plane A
Folding A
position
adjustment
key
Folding mode State of
folded
plane B
Folding B
position
adjustment
key
Single fold
A
A is long
key
Single fold
Folding plate 2 is not used.
A is short
key
Double
fold
A
A is long
key
Double
fold
B
B is long
key
A is short
key
B is short
key
Irregular
accordion
fold-out
A
A is long
key
Irregular
accordion
fold-out
B
B is long
key
A is short
key
B is short
key
Letter fold
A
A is long
key
Letter fold
B
B is long
key
A is short
key
B is short
key
