7
3. NAMES AND OPERATION OF PARTS
Control panel
Paper feeder A
Paper feed tray A
Auxiliary paper feed
plate A
Rear guide A
Sub guide A
Reference guide A
Side guide A
Side guide moving dial
A
Separator air
adjustment knob A
Separator adjustment
knob A
Auxiliary stack guide A
Separator air duct A
Separator A
Suction belt A
Level sensor A
Shutter A
For details, refer to “4. CONTROL PANEL”.
Paper feeder normally used.
Stacks the paper to be bound.
Prevents entangling of paper at the entrance of the paper feed tray A.
Remove when using paper less than 200 mm (7.87") wide.
Align to the rear edge of the paper stacked on the paper feed tray A to prevent
the deviation of paper by the separator air.
Holds the edge of conveyed paper to prevent deviation of paper.
Press paper against this when stacking.
Align to the left edge of the paper stacked on the paper feed tray A.
Turn to adjust the position of the side guide A.
Knob for adjusting the position of the shutter A to adjust the amount of separator
air blown out.
Knob for adjusting the position of the separator A.
Refer to “17. AUXILIARY STACK GUIDE A”.
Blows out air to separate paper stacked on the paper feed tray A.
Prevents double-feeding at the paper feeder A.
Sucks and conveys paper.
Sensor which determines the position of the paper raised by the separator air.
Adjusted using a knob.
For adjusting the amount of air blown out to separate paper by covering the
separator air duct A.
No. Name Operation
q
w
e
r
t
y
u
i
o
!0
!1
!2
!3
!4
!5
!6
!7
