60
Tower floor-type paper feeder (with cover feeder)
Belt suction system
Paper feeder A: 200 mm (7.87")
Paper feeder B: 60 mm (2.36")
Width : 148 to 320 mm (5.83" to 12.60")
Length: 200 to 450 mm (7.87" to 17.72")
Paper feeder A
Fine quality paper : 52 to 128 g/m
2
Art/coated paper : 79 to 128 g/m
2
Paper feeder B
Fine quality paper : 52 to 250 g/m
2
Art/coated paper : 79 to 157 g/m
2
Leaf
Maximum 150 sheets/minute (A4 vertical)
* But it depends on the specifications of the downstream processing unit if it is used.
Double-feed detection, mis-feed detection, paper jamming detection (paper feed
section)
Paper jamming detection (conveyance route), no-paper detection, upper door open/
close detection, lower door open/close detection, bridge door open/close detection, end
mark error detection
Reversal function (paper feeder A only)
DSF-2000: W × D × H = 1100 × 750 × 1015 mm (43.31" × 29.53" × 39.96")
DSF-2000 + DBM-120 Sheet by Sheet + DBM-120T + Stacker:
W × D × H = 2750 × 750 × 1015 mm (108.27" × 29.53" × 39.96")
DSF-2000 + DBM-400 Sheet by Sheet + DBM-400T + DBM-400LS:
W × D × H = 4500 × 750 × 1015 mm (177.17" × 29.53" × 39.96")
220 to 240 V AC 50/60 Hz
120 V AC 60 Hz
0.9 A (220 to 240 V AC)/1.8 A (120 V AC)
136 kg (299.56 lb)
Type
Feeding system
Maximum paper
loading volume
Paper size
Paper quality
Paper type
Processing speed
Feed error detection
Other detection
functions
Additional function
Dimensions
Power supply
Current consumption
Mass (Weight)
22. SPECIFICATIONS
Model DSF-2000
Specifications and dimensions are subject to change without prior notice for improvements.
