38
13. OTHER SETTINGS
13-5. Setting the Double-feed Detection Sensor
Turn the jog dial at the initial screen to display “Other Setting”, and press the jog dial to confirm
the setting.
1
The double-feed detection sensor compares the characteristics data of the paper test-fed and
paper being processed, and determines that double-feeding has occurred when the difference in
characteristics is large. The sensor also detects paper jams. The settings of the double-feed
detection sensor of the paper feeder need to be changed according to the paper and purpose.
Turn the jog dial to display “D-feed Sensor”, and press the jog dial to confirm the setting. Turn
the jog dial and select the item from (1) to (3) below to be changed, and press the jog dial to
confirm the setting.
2
(1) Setting the double-feed detection sensor of the paper feeder A
Select to use the double-feed detection function of the paper feeder A, and set the paper thickness, double-
feed detection sensitivity, and position to start double-feed detection.
Turn the jog dial to display “A Tray Setting”, and press the jog dial to confirm the setting.
(a) Using the double-feed detection function
Turn the jog dial to display “A Tray Check”, and press the jog dial to confirm the setting.
Turn the jog dial and display “On” at the left edge when using the double-feed detection function, and display
“Off” if not using the function, and press the jog dial to confirm the setting.
Check on/off
Off On
NOTE : When set to “Off”, the machine will not stop even when double-feeding occurs.
To Next Page
