10
4. CONTROL PANEL
4-1. Names and Operation of Control Panel
w Start button
e Stop button
button
Clear
button
Escape
r Jog dial
t Power ON indicator
q Display (LCD)
button
Function
y
i
u
Displays items, settings, and messages.
Press to operate the machine.
Press to stop the machine.
Turn to display the mode or value to be changed, and press to confirm the
changed mode or value.
Lights up in green when power is turned on.
Press to return to the previous item.
Use to operate only the conveyor (Forced ejection).
When entering numbers, turning the jog dial while pressing this button changes
the number in units of 100.
Press once at the initial screen to clear the number of processed sets to “0”. The
remaining number of sets display shows the value previously set.
Press at the numerical input screen to clear the setting to “0” or set the minimum
value which can be set.
No. Name Operation
q
w
e
r
t
y
u
i
Display (LCD)
Start button
Stop button
Jog dial
Power ON indicator
Escape button
Function button
Clear button
∗ When the machine is operating or the paper feed tray is moving up and down, all buttons will be ineffective.
(Only the stop button will be effective while the machine is operating.)
To Next Page
