17. AUXILIARY STACK GUIDE A

Use the auxiliary stack guide A if paper is fed crookedly.

Place it on the paper feed tray A so that it presses the sponge at the position where the left side of

the paper stacked or the rear end of the paper becomes crooked.

Auxiliary stack guide A

Paper feed tray A
