9. REVERSAL MECHANISM
When the reversal mechanism is used, the paper fed using the paper feeder A can be reversed
and sent to the downstream processing unit.
9-1. Selecting the Reversal Mechanism
When using the reversal mechanism, turn the jog dial at the initial screen to display “Inverter
Mode” and press the jog dial to confirm the setting.
1
Select Inv. Mode
Off On
Turn the jog dial and display “On” at the left edge when using the reversal mechanism, and
display “Off” if not using the reversal mechanism, and press the jog dial to confirm the setting.
2
Press the (Escape) button to return to the initial screen.
When use of the reversal mechanism is selected, “∗” will be displayed at the top right of the
initial screen.
3
A3 ∗
5555/7777(1O)
