64
9. VARIOUS SETTINGS
❊ Trimmer Settings 2
1
Adjust the driving time of the conveyance belt. The
standard setting is 1. Driving time can be selected
between 0 and 10 using the [
/ keys]. Increasing
the value increases the driving time.
If the trimming position is unstable because booklets
bounce back, from the stopper or slip, these problems
can be prevented by driving the belt longer.
2
Adjust the distance between the conveyance rollers.
The standard setting is 0. The distance can be
selected between –30 (minimum) to 30 (maximum)
using the [
/ keys].
If booklets cannot be conveyed smoothly due to the
difference in paper quality, thickness of booklets, etc.,
adjust this distance.
If booklets fail to enter the conveyance belts, the
distance may be too narrow. Adjust larger.
If booklets do not reach the stopper after entering
the conveyance belts, or are not ejected smoothly
after trimming, the distance may be too wide. Adjust
smaller.
Pressing the [Back key] returns to the <Trimmer
Setting 1> screen.
<Trimmer Setting 2> Screen
1
2
Back key
❊ Trimmer Settings 1
Adjust the finished length (length from book spine to fore-
edge).
Press the [Trimmer key].
1
Finished length
2
Increases by about 0.1 mm/0.004 inch.
3
Increases by about 1 mm/ 0.04 inch.
4
Decreases by about 1 mm/0.04 inch.
5
Decreases by about 0.1 mm/0.004 inch.
Pressing the [Back key] returns to the Accessory
Menu.
Pressing the [Next key] proceeds to the <Trimmer
Setting 2> screen.
23
45 1
Next key
Back key
Trimmer stopper
BookletSpine
Fore-edge
Blade
Finished length
Short Long
145. 5
<Trimmer Setting 1> Screen
The optional settings still remain effective even though the power is shut off.
To memorize these settings, start this machine and stop once.
The contents of each option setting is effective on all memory numbers.
To Next Page
