About the RTM (Rotary Tool Module)
Before Using This Module
1
REFERENCE
In this manual, the combination of the
upper tool holder assy
and the
lower tool assy
is
called
RTU (Rotary Tool Unit)
.
●
Document feed side
RTU (Rotary Tool Unit)
RTU (Rotary Tool Unit)
Adjustment knob
Lead shaft
Slide shaft
Driving shaft
Slide shaft
Lead shaft
Guide
Lower
tool assy
Lever angle
Lower tool
Rotary tool
Upper tool
holder assy
