Before Using This Module
1
How to Remove and Install the RTM (Rotary Tool Module)
Removing the RTM (Rotary Tool Module)
Open the
top cover
.
Disconnect the
connector
of the
RTM (Rotary Tool
Module)
.
Loosen the two
fi xing screws
on the
RTM (Rotary
Tool Module)
. Grasp the handles to take out the
RTM
(Rotary Tool Module)
by lifting it up.
Top cover
