11 | Appendix: Plans and drawings
102
D-LX 201/721
11.3.2 D-LX 201 with housing M5
A
Cable gland (plastic)
C
Adapter NPT ½"
B
Panel plug
Fig.11.3: The flame monitor can be fitted with either A, B or C for the electrical connection.
