Dynalink DL-WRX36 User Manual

5. SPECIFY ROUTER SETTINGS VIA WEB BROWSER
45
DHCP Server
Network
Select Main Network or Guest Network in the dropdown menu to configure DHCP server.
Enable DHCP Server
Select the radio button to enable or disable DHCP server.
Domain Name
The domain name of the network.
DHCP address Range
Define the start and end of the IP address range that the DHCP server will assign to the LAN devices connecting to
your router.
Lease Time
Enter the lease time in seconds that DHCP server will renegotiate with the LAN devices to release and renew IP
addresses.
Default Gateway
The router uses the IP address of default gateway to communicates with LAN devices and other networks.
DNS and WINS Server
DNS Server
Enter a Domain Name Server address.
WINS Server
Enter a Windows Internet Name Service address.
Static IP Assignment within DHCP IP Pool (Maximum: 64)
Enable Manual
Select the radio button to enable/disable static IP assignment within DHCP IP pool.

Dynalink DL-WRX36 Specifications

System Memory

flash memory	256 MB
RAM	1 GB DDR4

Ports & Interfaces

wireless interface	2.4GHz and 5GHz Dual-Band Concurrent
LAN ports	4 Gigabit LAN Port
WAN port	One 2.5 Gigabit WAN Port

Wireless Specifications

wireless standard	IEEE802.11a/b/g/n/ac/ax
frequency range 2.4 GHz	2.412 GHz ~ 2.4835 GHz
frequency range 5 GHz	5.15 GHz ~ 5.35 GHz, 5.47 GHz ~ 5.85 GHz

Antenna

antenna for 2.4 GHz	4-internal
antenna for 5 GHz	4-internal
maximum output power 2.4 GHz	29 dBm
maximum output power 5 GHz	29 dBm

Power

operating voltage	12V/2.5A DC adaptor (100V~240V, 50 Hz ~ 60 Hz)
maximum power consumption	26.8 Watts

Operating Environment

operating temperature	0°C ~ 40°C
storage temperature	-40°C ~ 85°C
operating humidity	5% ~ 90% RH
storage humidity	5% ~ 95% RH

Weight and Dimensions

width	100 mm
height	230.25 mm
depth	150 mm
