Dynalink DL-WRX36 User Manual

9. TECHNICAL SPECIFICATION
124
Technical Specification
Memory
FLASH: NAND 256MB RAM: DDR4 1GB
Interface
Wireless 2.4GHz and 5GHz Dual-Band Concurrent
4 Gigabit LAN Port + One 2.5 Gigabit WAN Port
Standard
IEEE802.11a/b/g/n/ac/ax
IEEE802.3, 10BASE-Te/100BASE-TX/1000BASE-T/2500BASE-T
Wireless Frequency Range
2.4 GHz: 2.412 GHz ~ 2.4835 GHz
5 GHz: 5.15 GHz ~ 5.35 GHz, 5.47 GHz ~ 5.85 GHz
Antenna
4-internal for 2.4 GHz
4-internal for 5 GHz
Maximum Output Power (with RF combine power)
29 dBm for 2.4 GHz
29 dBm for 5 GHz
Dimensions
W 100 x H 230.25 x D 150 mm
Button
Power, Reset to default, WPS
Indication
LED Indicators (2-color) Blue/Red
Operating Voltage
12V/2.5A DC adaptor (100V~240V, 50 Hz ~ 60 Hz)
Maximum Power Consumption
26.8 Watts
Temperature
Operating: 0oC ~ 40oC
Storage: -40oC ~ 85oC
Humidity
Operating: 5% ~ 90% RH
Storage: 5% ~ 95% RH

Dynalink DL-WRX36 Specifications

System Memory

flash memory	256 MB
RAM	1 GB DDR4

Ports & Interfaces

wireless interface	2.4GHz and 5GHz Dual-Band Concurrent
LAN ports	4 Gigabit LAN Port
WAN port	One 2.5 Gigabit WAN Port

Wireless Specifications

wireless standard	IEEE802.11a/b/g/n/ac/ax
frequency range 2.4 GHz	2.412 GHz ~ 2.4835 GHz
frequency range 5 GHz	5.15 GHz ~ 5.35 GHz, 5.47 GHz ~ 5.85 GHz

Antenna

antenna for 2.4 GHz	4-internal
antenna for 5 GHz	4-internal
maximum output power 2.4 GHz	29 dBm
maximum output power 5 GHz	29 dBm

Power

operating voltage	12V/2.5A DC adaptor (100V~240V, 50 Hz ~ 60 Hz)
maximum power consumption	26.8 Watts

Operating Environment

operating temperature	0°C ~ 40°C
storage temperature	-40°C ~ 85°C
operating humidity	5% ~ 90% RH
storage humidity	5% ~ 95% RH

Weight and Dimensions

width	100 mm
height	230.25 mm
depth	150 mm
