Dynalink DL-WRX36 User Manual

3. HARDWARE INSTALLATION
7
Hardware installation
1. Insert the power adapter into the WiFi Router’s power connector and plug it into the
power outlet.
2. Use the provided Ethernet cable to connect your computer to the WiFi Router’s LAN
port. Or, connect your mobile device to the Router via WiFi.
3. Use the Ethernet cable to connect your modem to the WiFi Router's Internet (WAN) port.
4. You can configure the router’s settings using a smartphone or a computer.
 Go to chapter 4. CONFIGURE ROUTER SETTINGS VIA MOBILE APP.
 Go to chapter 5. SPECIFY ROUTER SETTINGS VIA WEB BROWSER.

Dynalink DL-WRX36 Specifications

System Memory

flash memory	256 MB
RAM	1 GB DDR4

Ports & Interfaces

wireless interface	2.4GHz and 5GHz Dual-Band Concurrent
LAN ports	4 Gigabit LAN Port
WAN port	One 2.5 Gigabit WAN Port

Wireless Specifications

wireless standard	IEEE802.11a/b/g/n/ac/ax
frequency range 2.4 GHz	2.412 GHz ~ 2.4835 GHz
frequency range 5 GHz	5.15 GHz ~ 5.35 GHz, 5.47 GHz ~ 5.85 GHz

Antenna

antenna for 2.4 GHz	4-internal
antenna for 5 GHz	4-internal
maximum output power 2.4 GHz	29 dBm
maximum output power 5 GHz	29 dBm

Power

operating voltage	12V/2.5A DC adaptor (100V~240V, 50 Hz ~ 60 Hz)
maximum power consumption	26.8 Watts

Operating Environment

operating temperature	0°C ~ 40°C
storage temperature	-40°C ~ 85°C
operating humidity	5% ~ 90% RH
storage humidity	5% ~ 95% RH

Weight and Dimensions

width	100 mm
height	230.25 mm
depth	150 mm
