Dynalink DL-WRX36 User Manual

5. SPECIFY ROUTER SETTINGS VIA WEB BROWSER
95
5.7.2 Airtime Fairness
Airtime Fairness is a feature that boost the overall network performance by sacrifice a little bit of network time on your slowest devices.
Note: The relatively “slow” WiFi speed devices can be slow from either long physical distance, weak signal strength, or simply being a legacy device
with older technology.
When your router is connected to a large number of wireless clients at the same time, enabling Airtime Fairness can better balance bandwidth
allocation between devices, avoid bandwidth waste and slow devices slow down the entire network. In addition, if some of your devices (such as
mobile phones) are often far away from the router and the signal is not good, you should also enable Airtime Fairness to ensure the network quality
of other devices.
Enable ATF
Toggle the switch to enable or disable ATF.

Dynalink DL-WRX36 Specifications

System Memory

flash memory	256 MB
RAM	1 GB DDR4

Ports & Interfaces

wireless interface	2.4GHz and 5GHz Dual-Band Concurrent
LAN ports	4 Gigabit LAN Port
WAN port	One 2.5 Gigabit WAN Port

Wireless Specifications

wireless standard	IEEE802.11a/b/g/n/ac/ax
frequency range 2.4 GHz	2.412 GHz ~ 2.4835 GHz
frequency range 5 GHz	5.15 GHz ~ 5.35 GHz, 5.47 GHz ~ 5.85 GHz

Antenna

antenna for 2.4 GHz	4-internal
antenna for 5 GHz	4-internal
maximum output power 2.4 GHz	29 dBm
maximum output power 5 GHz	29 dBm

Power

operating voltage	12V/2.5A DC adaptor (100V~240V, 50 Hz ~ 60 Hz)
maximum power consumption	26.8 Watts

Operating Environment

operating temperature	0°C ~ 40°C
storage temperature	-40°C ~ 85°C
operating humidity	5% ~ 90% RH
storage humidity	5% ~ 95% RH

Weight and Dimensions

width	100 mm
height	230.25 mm
depth	150 mm
