Dynalink DL-WRX36 User Manual

5. SPECIFY ROUTER SETTINGS VIA WEB BROWSER
49
Basic
Frequency
Select 2.4GHz or 5GHz.
Setting
Network
Select Main Network or Guest Network.
WiFi Network ON/OFF
Enable or disable this WiFi band.
WiFi Network Name (SSID)
This is the name of your WiFi network for identification, also sometimes referred to as “SSID”. The SSID can
consist of any combination of up to 32 alphanumerical characters.
Broadcast SSID ON/OFF
Choose to broadcast SSID or to become hidden on Network.
Security Setting
Select a WiFi security type from the dropdown menu. WPA2 personal is the default. And WPA3 personal is the
most secure setting.
WPA Encryption
The encryption type displayed in the text field depends on the security mode. AES is the default encryption for
WPA2, WPA3, and WPA2/WPA3 Mix Mode, while TKIP+AES is default for WPA/WPA2 Mix Mode.
WiFi Password
Enter your WiFi password. The complexity of the password decides the security level of your WiFi network. The
password must be consisted of at least 8 characters or longer.
Protected Management Frames
Select Disable, Capable, or Required from the dropdown menu.

Dynalink DL-WRX36 Specifications

System Memory

flash memory	256 MB
RAM	1 GB DDR4

Ports & Interfaces

wireless interface	2.4GHz and 5GHz Dual-Band Concurrent
LAN ports	4 Gigabit LAN Port
WAN port	One 2.5 Gigabit WAN Port

Wireless Specifications

wireless standard	IEEE802.11a/b/g/n/ac/ax
frequency range 2.4 GHz	2.412 GHz ~ 2.4835 GHz
frequency range 5 GHz	5.15 GHz ~ 5.35 GHz, 5.47 GHz ~ 5.85 GHz

Antenna

antenna for 2.4 GHz	4-internal
antenna for 5 GHz	4-internal
maximum output power 2.4 GHz	29 dBm
maximum output power 5 GHz	29 dBm

Power

operating voltage	12V/2.5A DC adaptor (100V~240V, 50 Hz ~ 60 Hz)
maximum power consumption	26.8 Watts

Operating Environment

operating temperature	0°C ~ 40°C
storage temperature	-40°C ~ 85°C
operating humidity	5% ~ 90% RH
storage humidity	5% ~ 95% RH

Weight and Dimensions

width	100 mm
height	230.25 mm
depth	150 mm
