Dynalink DL-WRX36 User Manual

5. SPECIFY ROUTER SETTINGS VIA WEB BROWSER
52
Radio
Frequency
Select 2.4GHz or 5GHz.
Setting
Wireless Mode
2.4GHz: Select the wireless mode used for the router’s WiFi. Include g, g/n, n, ax/n/g.
5GHz: Select the wireless mode used for the router’s WiFi. Include a, n/a, ac, ac/n/a, ax/ac/n/a.
Channel Bandwidth
Set the channel bandwidth: 20MHz (lower performance but less interference), 40MHz (better performance but
likely more interference), or Auto (automatically select based on interference level).
Control Channel
Select a wireless radio channel or use the default “Auto” setting from the drop-down menu. Changing radio
channel can improve WiFi signal depending on how crowded the channel is with other radio signals and
interference.
Tx Power Adjustment
Tx Power adjustment refers to the milliWatts (mW) needed to power the radio signal output of the wireless route.
It could be 25%, 50%, 75%, or 100%.

Dynalink DL-WRX36 Specifications

System Memory

flash memory	256 MB
RAM	1 GB DDR4

Ports & Interfaces

wireless interface	2.4GHz and 5GHz Dual-Band Concurrent
LAN ports	4 Gigabit LAN Port
WAN port	One 2.5 Gigabit WAN Port

Wireless Specifications

wireless standard	IEEE802.11a/b/g/n/ac/ax
frequency range 2.4 GHz	2.412 GHz ~ 2.4835 GHz
frequency range 5 GHz	5.15 GHz ~ 5.35 GHz, 5.47 GHz ~ 5.85 GHz

Antenna

antenna for 2.4 GHz	4-internal
antenna for 5 GHz	4-internal
maximum output power 2.4 GHz	29 dBm
maximum output power 5 GHz	29 dBm

Power

operating voltage	12V/2.5A DC adaptor (100V~240V, 50 Hz ~ 60 Hz)
maximum power consumption	26.8 Watts

Operating Environment

operating temperature	0°C ~ 40°C
storage temperature	-40°C ~ 85°C
operating humidity	5% ~ 90% RH
storage humidity	5% ~ 95% RH

Weight and Dimensions

width	100 mm
height	230.25 mm
depth	150 mm
