Dynalink DL-WRX36 User Manual

5. SPECIFY ROUTER SETTINGS VIA WEB BROWSER
87
OpenVPN Server
Enable VPN Server
Enable or disable the VPN Server.
VPN Details
Select General or Advanced settings.
Export OpenVPN
Configuration File
Export the configuration file.
Username and Password
Select General and click the Add Rule button. Input the username and password to authenticate the devices to
the VPN server. Then click the Save button.
Advanced Settings
Interface Type
Select TUN to create a routed IP tunnel.
Protocol
Select TCP or UDP.
Server Port
The TCP/UDP port which OpenVPN server will listen on.
Authorization Mode
Select the authorization mode.
VPN Subnet / Subnet Mask
Configure the VPN subnet and subnet mask settings.
Local network only
Select Yes or No according to the requirement.
Internet and local network
Select Yes or No according to the requirement.
Encryption Cipher
Select a cryptographic method. This configuration item must be copied to the client configure file as well.

Dynalink DL-WRX36 Specifications

System Memory

flash memory	256 MB
RAM	1 GB DDR4

Ports & Interfaces

wireless interface	2.4GHz and 5GHz Dual-Band Concurrent
LAN ports	4 Gigabit LAN Port
WAN port	One 2.5 Gigabit WAN Port

Wireless Specifications

wireless standard	IEEE802.11a/b/g/n/ac/ax
frequency range 2.4 GHz	2.412 GHz ~ 2.4835 GHz
frequency range 5 GHz	5.15 GHz ~ 5.35 GHz, 5.47 GHz ~ 5.85 GHz

Antenna

antenna for 2.4 GHz	4-internal
antenna for 5 GHz	4-internal
maximum output power 2.4 GHz	29 dBm
maximum output power 5 GHz	29 dBm

Power

operating voltage	12V/2.5A DC adaptor (100V~240V, 50 Hz ~ 60 Hz)
maximum power consumption	26.8 Watts

Operating Environment

operating temperature	0°C ~ 40°C
storage temperature	-40°C ~ 85°C
operating humidity	5% ~ 90% RH
storage humidity	5% ~ 95% RH

Weight and Dimensions

width	100 mm
height	230.25 mm
depth	150 mm
