Dynalink DL-WRX36 User Manual

5. SPECIFY ROUTER SETTINGS VIA WEB BROWSER
89
1. Click . Enter the parameters in accordance with your requirements.
2. Click Apply to have the rule created on VPN client list and then click to apply your changes. You can modify or remove the rules
by using the and icons. Click the button to activate the connection.
Note: The maximum number on VPN Client list is 8 rules
VPN Type - PPTP
VPN Type
Select the VPN Type PPTP from the dropdown
menu.
Enable Default Route
Enable default route if requires.
Description
Specify the name.
VPN Server
Enter the server name or server IP of the VPN
Server.
Username
Enter the username.
Password
Enter the password.
PPTP Options
Select the PPTP Options Auto/No
Encryption/MPPE 40/ MPPE 128 from the
dropdown menu.

Dynalink DL-WRX36 Specifications

System Memory

flash memory	256 MB
RAM	1 GB DDR4

Ports & Interfaces

wireless interface	2.4GHz and 5GHz Dual-Band Concurrent
LAN ports	4 Gigabit LAN Port
WAN port	One 2.5 Gigabit WAN Port

Wireless Specifications

wireless standard	IEEE802.11a/b/g/n/ac/ax
frequency range 2.4 GHz	2.412 GHz ~ 2.4835 GHz
frequency range 5 GHz	5.15 GHz ~ 5.35 GHz, 5.47 GHz ~ 5.85 GHz

Antenna

antenna for 2.4 GHz	4-internal
antenna for 5 GHz	4-internal
maximum output power 2.4 GHz	29 dBm
maximum output power 5 GHz	29 dBm

Power

operating voltage	12V/2.5A DC adaptor (100V~240V, 50 Hz ~ 60 Hz)
maximum power consumption	26.8 Watts

Operating Environment

operating temperature	0°C ~ 40°C
storage temperature	-40°C ~ 85°C
operating humidity	5% ~ 90% RH
storage humidity	5% ~ 95% RH

Weight and Dimensions

width	100 mm
height	230.25 mm
depth	150 mm
