Dynalink DL-WRX36 User Manual

5. SPECIFY ROUTER SETTINGS VIA WEB BROWSER
91
VPN Type - OpenVPN
VPN Type
Select the VPN Type OpenVPN from the dropdown
menu.
Enable Default Route
Enable default route if requires.
Description
Specify the name.
Username
Enter the username.
Password
Enter the password.
Import .ovpn File
Select the file exported from the OpenVPN server.
Then click the Upload button.
Request CA/Key
Use the Yes/No radio button to request the CA/Key
if requires. Then configure the detailed options.
Import CA File
Select the specific CA file you would like to import.
Then click the Upload button.
Edit CA/Key
Manually edit the content of Certificate Authority,
Client Certificate, Client Key, and Static Key.

Dynalink DL-WRX36 Specifications

System Memory

flash memory	256 MB
RAM	1 GB DDR4

Ports & Interfaces

wireless interface	2.4GHz and 5GHz Dual-Band Concurrent
LAN ports	4 Gigabit LAN Port
WAN port	One 2.5 Gigabit WAN Port

Wireless Specifications

wireless standard	IEEE802.11a/b/g/n/ac/ax
frequency range 2.4 GHz	2.412 GHz ~ 2.4835 GHz
frequency range 5 GHz	5.15 GHz ~ 5.35 GHz, 5.47 GHz ~ 5.85 GHz

Antenna

antenna for 2.4 GHz	4-internal
antenna for 5 GHz	4-internal
maximum output power 2.4 GHz	29 dBm
maximum output power 5 GHz	29 dBm

Power

operating voltage	12V/2.5A DC adaptor (100V~240V, 50 Hz ~ 60 Hz)
maximum power consumption	26.8 Watts

Operating Environment

operating temperature	0°C ~ 40°C
storage temperature	-40°C ~ 85°C
operating humidity	5% ~ 90% RH
storage humidity	5% ~ 95% RH

Weight and Dimensions

width	100 mm
height	230.25 mm
depth	150 mm
