HYDRAULIC SCREW COMPRESSORS
GENERAL
1.5. MAIN COMPONENTS OF HKR COMPRESSOR
Picture 4: Main components of HKR compressor
1. Safety valve
2. Intake valve
3. Hydraulic motor
4. Temperature probe connection
5. Lifting eyes
6. DYNASET type plate
7. Intake filter
8. Air pressure control valve
9. Oil thermostat
10. Oil filler cap
11. Heat exchanger
12. Heat exchanger by-
pass check valve
13. Oil filter
14. Oil return line sight glass
15. Minimum pressure valve
16. Compressed air outlet (AP)
17. Oil drain plug
18. Compressor block
19. Hydraulic pressure line (P)
20. Hydraulic return line (T)
21. Air-oil separator element
