HYDRAULIC SCREW COMPRESSORS
OPERATION
If ambient temperature drops below -15 ºC or raises over + 45 ºC, make sure that
compressor is filled with synthetic oil. READ CHAPTER “6.3. Compressor oils” for
corresponding oils.
OIL
SYNTHETIC
MAX
MIN
0
+45
0
-15
< -15
o
C > +45
o
C
Picture 37: Operating in extreme ambient temperatures
5.4. AIR HUMIDITY
Compressor can be operated at the relative humidity up to 90%, provided that the
ambient temperature is within the above range.
AIR HUMIDITY
0%
100%
90%
0% 100%
90%
AIR HUMIDITY
< 90%
> 90%
Picture 38: Operating air humidity
ATTENTION!
When using HKR compressor on high ambient humidities, water can be
condensed in the compressor chamber. Condensed water may increase the
risk of saturation in air-oil separator element.
