HYDRAULIC SCREW COMPRESSORS
OPERATING PRINCIPLES
3.4. INTAKE VALVE
The Dynaset HKR is equipped with an integrated intake valve that is mounted
directly on the compressor housing. It is triggered via air pressure control valve.
11
2
Intake valve open Intake valve closed
3
4
Picture 8: Operating principles of intake valve
1. Air inlet
2. Air outlet
3. Control piston
4. Sping
