service manual
Issued 05/05
Fitting notes
Before attempting any repairs it is vital to ensure that the product is
totally isolated from the mains supply and that accidental
reconnection cannot occur.
Removing the cleanerhead and yoke assembly
General notes
6
Undo the two screws to the side of the yoke.
Slide the yoke cover away from the side of
the yoke to expose the connections.
1
2
Where this symbol is shown ensure ESD protection is used.
All screws used in DC15 are Torx T15, unless otherwise stated.
Assembly guide
The fitting notes contained within this service manual are separated into the following assembly
sections:
Cleanerhead and
yoke
Ball and motor
bucket
Cyclone and bin
Duct
Wand handle and
hose
Stabiliser and
axlestand
Valve
