EA Technology UltraTEV Plus
2
Operating Manual 2388L015
Page 7 of 66
5. Using the UltraTEV Plus²
The Temperature & Humidity and RFCT accessories plug into the Smart
Accessory Port. The UltraDish, Contact Probe and the Flexible Sensor plug
into the Ultrasonic Accessory Port
Smart
Accessory
Port
Right Button
Middle Button
Left Button
Home Button
Photo Sensor
microSD card slot
LED charging indicator
Audio out/headphone
socket
Ultrasonic
Accessory Port
Micro USB charging port
Ultrasonic Sensor
TEV sensor
Lanyard loop
