Operating Manual 2388L015
Page 9 of 66
5.3 Notification Bar
The notification bar is used to display basic status information about the UltraTEV Plus
2
. It
displays information such as Temperature, Humidity, Battery Level and other system
information as shown below. Additional information such as icons depicting the type of
accessory plugged in are also displayed here.
The Phase Reference indicator will turn red when a phase lock hasn’t been
achieved
Below are other icons that could appear on the notification bar:
This icon indicates that the current audio source is TEV
This icon indicates that the current audio source is Ultrasonic
This icon indicates that the current audio source is the RFCT
This icon shows when a UltraDish has been connected to the UltraTEV Plus²
This icon shows when a RFCT has been connected to the UltraTEV Plus²
This icon shows when a Contact Probe has been connected to the UltraTEV Plus²
This icon shows when a Flexible Sensor has been connected to the UltraTEV Plus
This icon shows when the UltraTEV Plus² is charging
This icon is used to show when a Wi-Fi connection has been established
Battery Level
Indicator
Temperature &
Relative Humidity
Audio
Source
Time
Phase
Reference
