EA Technology UltraTEV Plus

Operating Manual 2388L015

Page 28 of 66

5.9.3 Network Settings

This section allows the setting of the Wi-Fi feature of the UltraTEV Plus².

The Wi-Fi functionality can be switched on/off using the toggle button shown above. Select

‘Network Connect’ above to connect it to a Wi-Fi network.
