EA Technology UltraTEV Plus2 User Manual

EA Technology UltraTEV Plus
2
Operating Manual 2388L015
Page 10 of 66
5.3.1 Temperature & Humidity
The temperature and relative humidity reading is displayed on the notification bar only after
connection of the sensor.
The temperature and relative humidity sensor pictured below is connected to the Smart Accessory
Port on the left hand side of the instrument. The connection of the accessory automatically starts
the data collection with the latest reading being displayed in the notification bar at the top left of
the screen.
In order to allow use of other optional accessories whilst still displaying a reference temperature the
final reading on removal of the sensor is persisted. Additional brackets around the measurement
demonstrate that this is a historic reading.
5.4 Menu Bar
The menu bar is located at the bottom of the screen. It displays icons that correlate to the
Left, Middle and Right Buttons. The icons on the Menu bar change depending on which
mode the UltraTEV Plus
2
is in.
The Left button , Middle Button and Right Button can be pressed
to select the Main menu buttons respectively
