4. Operation
4.6 Transfer program to the easyE4 device
AUTOIP ✓
DHCP
STATIC IP
Table 53: System Option-
s\Ethernet\Address mode
Select the network setting you want.
Set up a new Ethernet connection on your PC's operating system.
To do this, go to Windows Network and Sharing Center and set up a LAN connection
over Internet Protocol Version 4 (TCP/IPv4). Then enter an IP address in the same
range you used for the device, but with a different device number.
Example using Windows
Figure 68: Ethernet connection on PC
You can now connect to your easySoft 7 device with the easySoft 7 programming soft-
ware.
See also
→ Section "Establishing an Ethernet connection", page 532
