2. Installation
2.5 External connections
2.5.2 Memory card
The slot for the microSD is located at the front of the base device.
Inserting a microSD card
Memory cards cannot be inserted the wrong way around.
Do not use force when inserting the card.
Pull out the slot.
Push the microSD card into the slot until you feel it lock into place.
Close the slot.
Figure 26: Inserting a memory card
62
easyE4 11/18 MN050009 EN www.eaton.com
