6. Function blocks
6.1 Manufacturer function blocks
Operands Value inputs
Constant, timer constant x
MD, MW, MB - Markers x
NB, NW, ND - NET markers x
nNB, nND, nND- NET markers
NET stations n
x
IA - Analog input x
QA - Analog output x
QV - QV - Numeric output of a FB x
You can assign the following operands to the function block inputs that are bit inputs:
Operands Bit inputs
Constant 0, constant 1 x
M – Markers x
RN - Input bit via NET x
SN - Output bit via NET (send) x
N - Net marker bit x
nN - NET marker bit NET station n x
ID: Diagnostic alarm x
LE - Output backlight x
P buttons x
I - Bit input x
Q - Bit output x
Q - Bit output of a FB x
Operating mode
BCD mode
The BCD value at I1 will be converted to a binary value and output at output QV. The bin-
ary value is displayed as a decimal value.
BIN mode
The binary value present at input I1 is converted to a BCD value and supplied at the out-
put QV. The binary value is displayed as a decimal value.
Description Note
BCD Converts a BCD value to a binary value.
BIN Converts a binary value to a BCD value.
Function block outputs
Description Note
(DWord)
QV Supplies the converted value. Integer value range
Decimal: -161 061 273…+161 061 273
BCD: -9 999 999… +9 999 999
Assigning operands
398
easyE4 11/18 MN050009 EN www.eaton.com
