Eaton easyE4 series User Manual

6. Function blocks
6.1 Manufacturer function blocks
Operands Bit inputs
LE - Output backlight x
P buttons x
I - Bit input x
Q - Bit output x
Q - Bit output of a FB x
Function block outputs
Description Note
(Bit)
OF Overflow
1: if QV ≥ SH
OF=1, if the actual value is
greater than or equal to the
upper threshold value;
FB Fall below
1: if QV ≤ SL
FB=1, if the actual value is less
than or equal to the lower
threshold value;
CY Carry
1: if QV > value range
If the value range is exceeded,
the switch contact switches to
status 1 for one cycle per rising
edge detected. The function
block retains the value of the last
valid operation before the con-
tact CY is set.
ZE Zero
1: if QV = 0
(DWord)
QV Current counter value in RUN mode Integer value range:
-2,147,483,648 to +2,147,483,647
Assigning operands
You can assign the following operands to the function block outputs that are numeric
outputs:
Assigning operands Outputs
Constant x
Markers: MB, MD, MW x
Analog inputs IA x
Analog output QA x
Numeric output from another QV FB x
You can assign the following operands to the function block outputs that are bit outputs:
Assigning operands Bit outputs
Constant 0, constant 1 x
M – Markers x
232
easyE4 11/18 MN050009 EN www.eaton.com
