Eaton easyE4 series User Manual

6. Function blocks
6.1 Manufacturer function blocks
The function block and its parameters
Function block inputs
Description Note
(Bit)
EN 1: Activates the function block.
(DWord)
I1 Input value Value range: -32768…+32767
TG Recovery time TG [0.1 s] Value range: 0…65535
The value 10 corresponds to a recovery
time of 1000 ms.
KP Proportional gain Kp [%]
Value range: 0 ... 65535
Value range: 0…65535
The value 100 corresponds to a KP
(factor) of 1.
The value 50 corresponds to a KP of 0.5.
Assigning operands
You can assign the following operands to the function block inputs that are numeric
inputs.
Operands Value inputs
Constant, timer constant x
MD, MW, MB - Markers x
NB, NW, ND - NET markers x
nNB, nND, nND- NET markers
NET stations n
x
IA - Analog input x
QA - Analog output x
QV - QV - Numeric output of a FB x
You can assign the following operands to the function block inputs that are bit inputs:
Operands Bit inputs
Constant 0, constant 1 x
M – Markers x
RN - Input bit via NET x
SN - Output bit via NET (send) x
N - Net marker bit x
nN - NET marker bit NET station n x
ID: Diagnostic alarm x
LE - Output backlight x
P buttons x
I - Bit input x
Q - Bit output x
Q - Bit output of a FB x
easyE4 11/18 MN050009 EN www.eaton.com
281
