6. Function blocks
6.1 Manufacturer function blocks
l States of function block trigger inputs T1 through T4 (DL01T1 through DL01T4 in this
example)
l Values at analog function block inputs I1 through I4 (DL01I1 through DL01I4 in this
example)
Counter Date Time Time (ms) DL01T1 DL01T2 DL01T3 DL01T4 DL01I1 DL01I2 DL01I3 DL01I4
0 2018-07-26 12:08:40 365 1 0 0 0 1480 2321 0 0
1 2018-07-26 12:08:40 968 1 1 0 0 1480 2322 0 0
2 2018-07-26 12:08:42 965 1 0 0 0 1479 2321 0 0
3 2018-07-26 12:08:43 677 0 1 0 0 1479 2322 0 0
4 2018-07-26 12:08:45 579 1 0 0 0 1480 2322 0 0
5 2018-07-26 12:08:46 908 0 1 0 0 1480 2321 0 0
6 2018-07-26 12:08:51 529 1 0 0 0 1480 2321 0 0
7 2018-07-26 12:08:52 332 0 1 0 0 1477 2322 0 0
8 2018-07-26 12:08:53 367 1 0 0 0 1480 2319 0 0
9 2018-07-26 12:08:54 151 0 1 0 0 1479 2322 0 0
10 2018-07-26 12:08:54 729 1 0 0 0 1480 2322 0 0
11 2018-07-26 12:08:55 155 1 1 0 0 1480 2322 0 0
12 2018-07-26 12:08:56 675 1 0 0 0 1480 2322 0 0
13 2018-07-26 12:08:56 677 1 1 0 0 1480 2322 0 0
14 2018-07-26 12:08:57 598 1 0 0 0 1480 2321 0 0
15 2018-07-26 12:08:57 607 1 1 0 0 1480 2321 0 0
16 2018-07-26 12:08:58 493 0 1 0 0 1480 2322 0 0
17 2018-07-26 12:08:58 494 1 1 0 0 1480 2322 0 0
18 2018-07-26 12:08:59 355 1 1 0 0 1481 2321 0 0
19 2018-07-26 12:09:00 198 0 1 0 0 1481 2322 0 0
20 2018-07-26 12:09:00 201 1 1 0 0 1481 2322 0 0
21 2018-07-26 12:09:01 56 0 1 0 0 1481 2322 0 0
22 2018-07-26 12:09:01 60 1 1 0 0 1481 2322 0 0
23 2018-07-26 12:09:02 523 1 0 0 0 1481 2322 0 0
24 2018-07-26 12:09:02 525 1 1 0 0 1481 2322 0 0
25 2018-07-26 12:09:03 445 0 1 0 0 1480 2321 0 0
26 2018-07-26 12:09:03 447 1 1 0 0 1480 2321 0 0
There are 26 data sets logged in this log file. The logging for all the data sets was
triggered by a rising edge at one of the digital inputs, e.g., data sets 0 through 2 by a
DL01T01=1 trigger and data set 3 by a DL01T04=1 trigger. Log files do not include any
information regarding the operating mode.
See also
→ Section "AL - Alarm function block", page 349
→ Section "BV - Boolean operation", page 353
→ Section "D - Text display", page 357
→ Section "D - Text display editor", page 366
→ Section "JC - Conditional jump", page 386
→ Section "LB - Jump label", page 391
→ Section "MR - Master reset", page 393
→ Section "NC - Numerical converter", page 397
→ Section "DL - Data logger", page 380
easyE4 11/18 MN050009 EN www.eaton.com
385
