Appendix
A.3 Technical data
Ambient climatic conditions
Air pressure (in operation) 795 - 1080 hPa
max. 2000 m NHN
Temperature
Operation
- 25 – +55 °C (-13 – +131 °F)
The display is readable between ϑ -5°C (-23°F) ≦ T ≦ 50°C (122°F).
Storage / Transport - 40 – +70 °C (-40 – +158 °F)
Humidity Relative humidity 5 - 95 %
Condensation Prevent condensation by means of suitable measures
EASY-E4- UC -12RC1 UC-12RCX1 DC -12TC1 DC-12TCX1
Eaton Catalog No. 197211 197212 197213 197214
Basic function Control relay,
expandable with I/O expansions from the easyE4 series;
Ethernet port for connecting to a network
Real-time clock
Display with keypad Monochrome
6 x 16 lines
- Monochrome
6 x 16 lines
-
Specifications for con-
nection to supply voltage
12/24 VDC, 24 VAC 24 V DC
Input points Digital: 8,
of which 4 can be used as analog inputs
Connection type Screw terminal, (AWG 22 - 12)
solid 0.2 - 4 mm², flexible with ferrule 0.2 - 2.54 mm²,
Mounting Tophat rail IEC/EN 60715 (35mm) or screw fixing with fixing brackets ZB4-101-
GF1 (accessories)
Protection rating
(IEC/EN 60529, EN 50178, VBG
4)
IP 20
Electromagnetic
compatibility (EMC)
Overvoltage category/pollution degree III/2
Radio interference sup-
pression
EN 61000-6-3 Class B
Ethernet
Porting RJ45 plug, 8-pin
Wire type CAT5
Table 108: Ethernet
easyE4 11/18 MN050009 EN www.eaton.com
585
