2. Installation
2.4 Connection terminals
Figure 23: Connecting analog outputs EASY-E4-DC-6AE1
DANGER
Analog signals are more sensitive to interference than digital signals,
therefore the signal cables should be carefully routed and connected.
An incorrect connection can lead to unwanted switching states.
The following measures must be adhered to in order to prevent any deviations in analog
values.
→ Section "Tips for analog signals", page 53
easyE4 11/18 MN050009 EN www.eaton.com
59
