3. Commissioning
3.3 Switch on
Line 5 The device's MAC address or device name;
displayed only if a name has been assigned
Line 6 IP address; displayed only if an address has been assigned
Status indicator 2
Displays set diagnostic bits ID1 through ID24:
state display with "0" and "1" for each bit
Line 1 Bit number for each block
Line 2 ID 1 ... ID 8:
Line 3 ID 9 ... ID 16
Line 4 ID 17 ... ID 24
Line 5 Free
Line 6 Current device operating mode
Press the ALTbutton.
Shows additional indicators.
I 1 . . 4 . 7 8 . .
N T 1 P
MO 1 3 : 0 8
Q 1 . . 4 R U N
M A C : 0 0 2 2 C 7 1 2 3 4 3 E
1 6 7 . 6 7 . 3 . 1
Figure 50: Example of status display on display
You can use the main menu from the status display in order to access the individual sub-
menus.
Press the OK button.
The main menu will appear.
STOP ✓ RUN
PARAMETERS
SETCLOCK
CARD
INFORMATION
SYSTEM-OPT.
PROGRAM
Table 4: Main menu
See also
→ chapter "3 Operation", page 87
82
easyE4 11/18 MN050009 EN www.eaton.com
