Page #26 background imageLoading...
Page #26 background image
3. Setting and Unsetting i-on16
Page 20
b. Either key in your access code.
As you key in your code the
display shows a “*” for each digit.


OR present your tag.
Quick Set:
In a part setting system, quick set removes the need to use an access code
or tag to start setting. The installer must enable this facility for you. (Note
that in order to make the alarm system comply with certain regulations the
installer may not be allowed to provide this facility.)
Do this:
The display shows:
a. Press A, B, C or D.
The system starts the exit
process, there is no need to select
what to set. Go to: 3. Finishing
Setting.


2. Selecting What to Set:
Do this:
The display shows:
The bottom line of the display
shows the first item in the setting
options menu.


a. Press or to select the option
you want.
The bottom line of the display
shows each item from the rest of
the menu in turn.


3. Finishing Setting
Depending on how your installer has programmed your system, you will
need to take one of the following actions to complete setting the system.
Note that you will need a special button fitted in order to use Exit Terminate
Set, and a special lock fitted to use Lock Set.
